The ACD Series is a revolutionary precision surface-finishing solution engineered by Huzhou Antron Machinery specifically for high-volume processing of small precision components. Utilizing a variable-frequency motor-driven high-speed rotating disc (0–180 rpm stepless adjustable), the system generates a three-dimensional centrifugal force field within a sealed chamber, enabling simultaneous deburring, polishing, edge radiusing, descaling, and cleaning in a single pass. Compact, fully automated, and exceptionally efficient, this machine is the ideal upgrade for industries such as automotive, aerospace, medical devices, and precision hardware.
Technical data：
Model | Volume/L | Machine size/MM | Motor power | Machine weight/KG | Rotary speed/RPM | Inter size/MM | PU thickness | ||||
Host power | Vibrating power | Speed power | |||||||||
ACD50 | 50 | 1040x11601140 | 1.5 | 0.12x2 | 0.75 | 350 | 0-180 | 460 | 25 | ||
ACD120 | 120 | 1600x1320x1340 | 4 | 0.12x2 | 0.75 | 900 | 0-170 | 640 | 30 | ||
ACD240 | 230 | 1620x1980x1500 | 5.5 | 0.25x2 | 0.75 | 1100 | 0-130 | 840 | 30 | ||
Video：
| **Core Component** | **Industry-Leading Design** |
| ---------------------------- | ----------------------------------------------------------------------------------------------------- |
| **High-Energy Rotor** | Aircraft-grade aluminum monoblock, dynamic balance ≤0.03 g, speed fluctuation ±0.5 rpm. |
| **Variable-Frequency Drive** | Siemens vector inverter + closed-loop torque control, **30% energy savings**, overload auto-shutdown. |
| **Cast-In PU Lining** | **Non-sprayed, 26–30 mm thick**, 5× longer wear life, **60% lower maintenance costs**. |
| **Smart Rinse System** | Automatic dosing pump, **≥95% solution recycling**, eco-friendly and cost-efficient. |
| **Modular Expansion** | Supports auto-loading, double-layer screen separation, and other upgrades for future scalability. |
